European Modular Cylinder B | GERDA SLR outside 30 / inside 30-61

Description

This is a cam cylinder. Its modular construction gives a full range of size adjustment on the inside of the door.

On the outside the cylinder unlocks with a traditional key. On the inside it carries a shaft designed for simple, secure mounting of the Tedee PRO smart lock.

Extra keys can be ordered from GERDA or authorised locksmiths with the included key-code card. Certified to security class 6 according to PN-EN 1303:2015-07.

Note: this cylinder can also be used to install Tedee GO 2 or Tedee GO smart locks with the dedicated Bar adapter (sold separately).

Available lengths on the Tedee shaft side (inside)

• 30 mm (no spacers)
• 36 mm (1 x 6 mm spacer)
• 40 mm (1 x 10 mm spacer)
• 45 mm (1 x 15 mm spacer)
• 46 mm (1 x 6 mm + 1 x 10 mm spacers)
• 51 mm (1 x 6 mm + 1 x 15 mm spacers)
• 55 mm (1 x 10 mm + 1 x 15 mm spacers)
• 61 mm (1 x 6 mm + 1 x 10 mm + 1 x 15 mm spacers)

Keyhole side (outside)

30 mm

Box contents

• Cylinder
• 3 x spacers (6, 10, 15 mm)
• 3 x spacer shafts (6, 10, 15 mm)
• 12 x clamping screws
• 3 x protective / damping stickers
• Mounting screw
• 3 x keys
• Key-code card
• Allen key
• Documentation
